Replacing Metal Door Casings With Wood
When replacing metal door casings with wood you should be careful to pay attention to the exterior door casing and the door itself so that you don’t damage anything vital to the installation. There are many variations of wood door casing profiles to choose from such as custom cuts and stock patterns so once you have selected your favourite you can officially start this project! Read on to learn about the replacement process.
Materials That You Will Need to Replace Your Metal Door Casing :
- Pry Bar
- Circular Saw
- Tape Measure
- Reciprocating Saw
- Nails (framing nails 10d)
- Nail Gun
- Wood Door Casing
- 2×4 studs
- Speed Square
1. Remove the Old Door/Frame before replacing Metal door Casing
- Take off the surrounding trim carefully if you wish to reuse it. Using a pry bar, gently lift the trim free of the nails and put in a safe place.
- Using a circular saw, cut through the nails that are holding the old door piece to the frame and slide the door out.
- Saw off and remove the studs that are around the opening of the door and remove the drywall strip or paneling on both sides so you can reach the door frame.
2. Measure the Metal Door Casing
- Using a tape measure, measure the door and pencil in the width of it on the horizontal boards that join the top and bottom of the wall frame. Also pencil in the height of the new door on the wall studs.
3. Cut & Measure
- With a circular saw, cut a pair of 2×4 studs so it will fit between the horizontal wall frame boards and insert them. Nail the top and bottom boards in and make sure they are nailed in diagonally through each side.
- Now cut another pair of 2×4 studs to the height of the exterior door and put them next to the studs that were just installed. Nail them to the studs as well as the boards at the top and bottom wall frame.
- Find the distance from the studs, they should be 3-3/4″ greater than the width of the doorway and cut a single 2×4 stud to that width. Put it on top of the studs and nail it to both sets of studs to create the header of the exterior door frame.
- Again, measure the distance from the header to the top of the wall frame and cut one 2×4 stud to that height, you’ll want to put it vertically onto the midpoint of the header and then nail up through the header and secure it.
- Nail diagonally through and into the top frame wall board to create the cripple stud for the door frame.
- Now you have completed the new door frame and can refinish the surrounding areas if necessary.
If you find that the bottom wall frame board might happen to extend into the doorway, just saw it off and make it clear.
Replacing metal door casings with wood can be done with a few tools and materials and it provides years of lasting and durable results. If you would like some assistance with metal door casing jobs, don’t hesitate to call Home Painters Toronto! Call us NOW at 416-494-9095 or email [email protected]!
